# Code Scanner Configuration

This step is required to configure the **Code (By Brady) brand scanners** to ensure accurate extraction of critical item details, including lot number and expiration date, from the item barcode.

#### **Why Configuration is Required**

Barcodes may contain multiple data elements in a single scan. Without proper configuration:

- Lot numbers may not be captured correctly
- Expiration dates may be missed or misread
- Data may appear as one continuous string instead of structured fields

This setup ensures the scanner parses and outputs data in a structured and usable format.

### Instruction

Step 1: Reset the Scanner.

Scan the barcode below labeled CC004361\_05. This will reset all programming on the scanner

![QR\_RESET (1) (1) (1)-20260429-133055](https://help.labsymplified.com/hs-fs/hubfs/QR_RESET%20(1)%20(1)%20(1)-20260429-133055.png?width=368&height=434&name=QR_RESET%20(1)%20(1)%20(1)-20260429-133055.png)

Step 2: Reboot & Reconnect the Scanner.

Follow the steps below:

1. Remove the battery from the scanner
2. Wait a few seconds
3. Insert the battery back in
4. Allow the scanner to reconnect to the cradle

Status Indicators:

- Green light → Successfully connected
- Red light / not connected → Scan the pairing barcode on the cradle/base

Step 3: Apply Configuration Code.

Scan the barcode below labeled CC00

![CC00-20260429-140315](https://help.labsymplified.com/hs-fs/hubfs/CC00-20260429-140315.png?width=458&height=524&name=CC00-20260429-140315.png)

Step 4: Set Enter Key Suffix.

Scan the barcode below labeled **M20219\_02**

**![image-20260429-144032](https://help.labsymplified.com/hs-fs/hubfs/image-20260429-144032.png?width=225&height=236&name=image-20260429-144032.png)**

Step 5: Scan a product barcode in the **Lab Symplified Check-In screen**. Verify that the item is recognized correctly and that the **lot number** and **expiration date** are captured accurately.

> - These steps **reset all previous configurations**, including any LIS-specific setup
> - We recommend using this scanner **only for Lab Symplified inventory workflows**
